SYIM03M60ATA: 600V/3A, 3-phase IPM with built-in drivers
Package Type: DIP-23\nRDS(on)@Typ.Tj=25°C: 2.5\nHighly integrated 600V/3A three-phase IPM with built-in drivers and protection, offering high reliability, excellent thermal stability, and simplified system design.\nIt is suitable for use in inverters for refrigerator compressors, air conditioner compressors, dishwashers, etc.
更多详情
Applications:
- Frequency converter
- Air Conditioning compressor
- Air cleaner
- Dish washer
- Cooker hood
- Refrigerator compressor
Features:
- Integrated 6 fast recovery power MOSFETs
- Integrated high voltage gate drive circuit
- Compatible with 3.3 V & 5 V input signal, effective at high level
- Integrated temperature output
- Built-inquick recovery boot strap diode
- Insulation class 1500 Vrms / min
- Integrated bootstrap functionality
- High reliability and thermal stability, good parameter consistency
Internal Electrical Schematic:
